Raymon Kirana Pure gravel bike Anthracite

Description

Raymon Kirana Pure gravel bike Anthracite is a fast gravel bike on 28" wheels designed for a mix of asphalt, gravel, and light farm tracks. It targets experienced riders who want the confidence of hydraulic disc brakes and a wider gear range for longer rides. Its spec places it in the mid-performance category, with an emphasis on a practical gravel and bikepacking setup.

Frame and geometry

At its core is a unisex carbon composite frame, Carbon MLC Composite, built for efficient power transfer when pedaling. The Carbon Road Disc fork supports disc brakes and stable tracking on rough surfaces. The bike is built around a 28" platform and uses 12 × 100 mm and 12 × 142 mm thru-axles. Available frame sizes are 48, 52, 54, 56, 58, and 60.

Components

Drivetrain: Shifting is handled by Shimano Tiagra in a 2×11 setup with ST-R4020 shifters and an RD-R4000 rear derailleur. The FC-R4000 50/34T crankset works with a CS-RS400 11–36T cassette and a CN-LG500 chain.

Brakes: Braking comes from Shimano BR-RS405 hydraulic disc brakes with two-piston calipers. Shimano SM-RT10 rotors are 160 mm in diameter and use Center Lock mounting.

Wheels and tires: Raymon T260/DH866 wheelset uses 12 × 100 mm and 12 × 142 mm thru-axles. Schwalbe One Performance tires in 30-622 are designed for fast riding on asphalt as well as hardpacked gravel.

Cockpit: Raymon alloy 31.8 mm handlebars are paired with a Raymon 31.8 stem. Contact points are handled by a Raymon 140 SL VM Fit saddle and a Raymon 27.2 mm seatpost with 15 mm offset.

Ride characteristics

The carbon frame and carbon fork increase torsional stiffness during acceleration and help the bike hold its line at higher speeds. The 50/34T front gearing and 11–36T cassette provide a usable range for longer climbs as well as brisk riding on the flats. Hydraulic disc brakes with 160 mm rotors support repeated braking on descents and in wet conditions. The 30-622 tires steer the bike’s character toward fast gravel riding and asphalt transfers.

Who it’s for

Raymon Kirana Pure is intended for riders who want a gravel bike for all-day rides, brisk training sessions, and light bikepacking. You’ll appreciate it if you prefer drop handlebars, a mechanically straightforward 2×11 drivetrain, and hydraulic disc brakes. Within the mid-range class, it relies on proven Shimano Tiagra components and a carbon frameset.

Key specifications

• Frame: 28", Carbon MLC Composite, unisex
• Fork: Carbon Road Disc
• Shifters: Shimano Tiagra ST-R4020, 2×11
• Crankset and cassette: Shimano Tiagra FC-R4000 50/34T + Shimano CS-RS400 11–36T
• Brakes: Shimano BR-RS405, hydraulic disc, 2 pistons
• Rotors: Shimano SM-RT10 160 mm, Center Lock
• Wheels and axles: Raymon T260/DH866, 12 × 100 mm and 12 × 142 mm
• Tires: Schwalbe One Performance 30-622

EAN: 788364357250
